S-Works Shiv TT Disc Module - FACT 11r Carbon

Model Summary

For years, time trial bikes have shared the same DNA: skinny, deep airfoils, sketchy handling, subpar braking, and heavy frames. Those qualities may have been acceptable for the flat-and-fast courses of yesteryear, but today's technically demanding courses called for a change. With the Shiv TT, we pushed UCI regulations to their limits — adding disc brakes, dropping weight, and dialling in the fit. Years of Retül data and professional rider feedback reshaped the geometry and front end, while updated spacers, bridge, and armrests lock in a stable, confident position. The result is one of the most adjustable TT bikes out there, without giving up anything to aerodynamics. The S-Works Shiv TT Disc Module is the perfect canvas to build your own TT dream rig — supplied as a complete frame, fork, integrated cockpit, and seatpost, ready for the drivetrain and finishing kit of your choice.

Key Highlights

• S-Works FACT 11r Carbon frame: a Win Tunnel—engineered, UCI-legal chassis with an all-new silhouette that cuts weight and sharpens handling versus the previous-generation Shiv.
• Disc brakes for real-world courses: confident late-braking into corners, on-the-bars shifting, and a more stable chassis in variable weather and rough surfaces — with no aero penalty.
• Retül-informed fit and adjustability: reworked spacers, bridge, and armrests lock in position for a genuinely dialled, stable ride across a wide range of rider dimensions.
• Integrated one-piece cockpit: the Specialized Shiv TT integrated bar/stem aerobar simplifies and lightens the front end while cleaning up airflow.
• Build-your-own module: supplied as frame, fork, integrated cockpit, seatpost, headset, and hardware only — the ideal blank canvas for a custom electronic-groupset build.

Technical Specifications

• Frame: S-Works FACT 11r Carbon, Win Tunnel Engineered, UCI Legal, internal electronic-only cable routing, BSA threaded BB, 12x142mm thru-axle, flat-mount disc
• Fork: S-Works FACT Carbon, integrated, 12x100mm thru-axle, flat-mount disc
• Headset: Fully integrated, proprietary Shiv TT Disc headset
• Bottom Bracket: BSA threaded
• Cockpit: Specialized Shiv TT integrated bar/stem aerobar, one-piece carbon construction (400mm width / 75mm stem length, standardised across sizes)
• Seatpost: S-Works Venge aero seatpost, FACT Carbon, Di2-compatible, integrated wedge clamp, 390mm length
• Tyre Clearance: up to 700x24c recommended; compatible with 140mm or 160mm disc rotors
• Geometry: head angle 71–72°, seat angle 74.5–75.75° depending on size (XS–L)
• Drivetrain Compatibility: electronic shifting only; bolt-on front derailleur mount supports 1x or 2x setups
• Included: frame, fork, integrated cockpit, seatpost, headset, and mounting hardware (module only — no groupset, wheels, or saddle)
• Weight: 2.69kg / 5lb 14.9oz (assembled module, size Medium)
